Product Details
| Data Sheet | Click here to download |
|---|---|
| Usually Ships Within | 3-5 Days |
| Factory Location | Batavia, Illinois |
| Material | Steel |
| Shape | 45-Degree |
| Fitting Style | Rigid |
| Series | A-MSP4 |
| Country of Manufacture | Italy |
| Height | 0.98 |
| Length | 6.54 |
| Width | 0.98 |
| Weight | 0.4 |
| Side 1 Size | 3/4 (-12) |
| Side 1 Type | Hose |
| Side 2 Gender | Male |
| Side 2 Size | 25mm |
| Side 2 Type | Standpipe |
Description
The Alfagomma A-MSPS Two-Piece Fittings are straight, carbon steel hose fittings designed to connect hoses to a system using a metric straight standpipe. These fittings are commonly used in applications where secure and durable hose connections are needed. Ferrules are metal components that are inserted into the hose end and help create a tight, leak-proof seal when the hose is attached to the fitting. The main difference between two-piece and one-piece fittings is that two-piece fittings consist of separate parts—like a fitting and a ferrule—allowing for easier installation and replacement of parts, while one-piece fittings are a single, solid unit that must be replaced as a whole if damaged. The A-MSPS Two-Piece Fittings are compatible with wire and textile braided hoses, thermoplastic hoses, Flexor 4, PTFE hoses, and Alfabiotech hoses ranging from ³⁄₁₆" to 2" in diameter, providing a flexible and reliable solution for high-pressure applications.
