Product Details
| Data Sheet | Download Datasheet |
|---|---|
| Usually Ships Within | 1-3 Days |
| Factory Location | Alpena, Michigan |
| Material | Magnesium |
| Bore Size | 2.375 (2-3/8") |
| Country of Manufacture | United States |
| Height | 11.4 |
| Length | 4.95 |
| Width | 11.4 |
| Weight | 38 |
Description
Magnaloy is the original lightweight, heavy-duty flexible drive coupling. Light weight magnesium construction makes Magnaloy couplings 76 percent lighter than cast iron and 36 percent lighter than aluminum units... and theyÕre stronger than either. The benefits are many... Reduced loads on bearings, shafts and pumps, for longer component life. Easier handling and installation. Rust proof and corrosion resistant. Magnaloys close machining tolerances (TIR of .002Ó) assures vibration-free operation and easy, accurate alignment without need for special tools. Solid magnesium alloy permanent mold castings are heat treated and offer the highest strength-to-weight ratio available. The Premium Line of Magnaloy Couplings comes standard with a single set-screw over the keyway. Optional Double Set-Screws are available at either 45 degree or 90 degree to the keyway. Double set-screws help improve shaft gripping forces by increasing the hoop-stresses generated from tightening a single set-screw. Double set-screws at 45 degrees will produce greater forces than double set-screws at 90 degrees. Either are available upon request by specifying DSS45 or DSS90 following the hub part number, for example M30011210DSS45. Magnaloys Clamp feature is also availble with bored and keyed hubs, specify C following the hub part number, for example M30011210C.
| Product SKU | Model | Coupling Series | Coupling Type | Bore Size | Key Size | Lead Time | Price |
|---|---|---|---|---|---|---|---|
| M90012414S | 900 1-3/4BX7/16K : Magnaloy 900 HUB 1-3/4" BORE X 7/16" KEY SPECIAL | 900 | Keyed | 1.75 (1-3/4") | 0.4375 (7/16") | 1-3 Days | $936.99 |
| M90011214S | 900 1-3/8BX7/16K : Magnaloy 900 HUB 1-3/8" BORE X 7/16" KEY SPECIAL | 900 | Keyed | 1.375 (1-3/8") | 0.4375 (7/16") | 1-3 Days | $936.99 |
| M90012816 | 900 1-7/8BX1/2K : Magnaloy 900 HUB 1-7/8" BORE X 1/2" KEY | 900 | Keyed | 1.875 (1-7/8") | 0.5 (1/2") | 1-3 Days | $901.99 |
| M900M10028 | 900 100MMBX28MMK : Magnaloy 900 HUB 100MM BORE X28MM KEY METRIC SPECIAL | 900 | Keyed | 100mm | 28mm | 1-3 Days | $936.99 |
| M90021620 | 900 2-1/2BX5/8K : Magnaloy 900 HUB 2-1/2" BORE X 5/8" KEY | 900 | Keyed | 2.5 (2-1/2") | 0.625 (5/8") | 1-3 Days | $901.99 |
| M90020816 | 900 2-1/4BX1/2K : Magnaloy 900 HUB 2-1/4" BORE X 1/2" KEY | 900 | Keyed | 2.25 (2-1/4") | 0.5 (1/2") | 1-3 Days | $901.99 |
| M90020416 | 900 2-1/8BX1/2K : Magnaloy 900 HUB 2-1/8" BORE X 1/2" KEY | 900 | Keyed | 2.125 (2-1/8") | 0.5 (1/2") | 1-3 Days | $901.99 |
| M90020420 | 900 2-1/8BX5/8K : Magnaloy 900 HUB 2-1/8" BORE X 5/8" KEY SPECIAL | 900 | Keyed | 2.125 (2-1/8") | 0.625 (5/8") | 1-3 Days | $936.99 |
| M90023024S | 900 2-15/16BX3/4K : Magnaloy 900 HUB 2-15/16" BORE X 3/4 KEY SPECIAL | 900 | Keyed | 2.9375 (2-15/16") | 0.75 (3/4") | 1-3 Days | $936.99 |
| M90022420 | 900 2-3/4BX5/8K : Magnaloy 900 HUB 2-3/4" BORE X 5/8" KEY | 900 | Keyed | 2.75 (2-3/4") | 0.625 (5/8") | 1-3 Days | $901.99 |
| M90022428S | 900 2-3/4BX7/8K : Magnaloy 900 HUB 2-3/4" BORE X7/8" KEY SPECIAL | 900 | Keyed | 2.75 (2-3/4") | 0.875 (7/8") | 1-3 Days | $936.99 |
| M90021224S | 900 2-3/8BX3/4K : Magnaloy 900 HUB 2-3/8" BORE X 3/4 KEY SPECIAL | 900 | Keyed | 2.375 (2-3/8") | 0.75 (3/4") | 1-3 Days | $936.99 |
| M90021220 | 900 2-3/8BX5/8K : Magnaloy 900 HUB 2-3/8" BORE X 5/8" KEY | 900 | Keyed | 2.375 (2-3/8") | 0.625 (5/8") | 1-3 Days | $901.99 |
| M90022020 | 900 2-5/8BX5/8K : Magnaloy 900 HUB 2-5/8" BORE X 5/8" KEY | 900 | Keyed | 2.625 (2-5/8") | 0.625 (5/8") | 1-3 Days | $901.99 |
| M90022824 | 900 2-7/8BX3/4K : Magnaloy 900 HUB 2-7/8" BORE X 3/4" KEY | 900 | Keyed | 2.875 (2-7/8") | 0.75 (3/4") | 1-3 Days | $901.99 |
| M90020016 | 900 2BX1/2K : Magnaloy 900 HUB 2" BORE X 1/2" KEY | 900 | Keyed | 2" | 0.5 (1/2") | 1-3 Days | $901.99 |
| M90031628 | 900 3-1/2BX7/8K : Magnaloy 900 HUB 3-1/2" BORE X 7/8" KEY | 900 | Keyed | 3.5 (3-1/2") | 0.875 (7/8") | 1-3 Days | $901.99 |
| M90030824 | 900 3-1/4BX3/4K : Magnaloy 900 HUB 3-1/4" BORE X 3/4" KEY | 900 | Keyed | 3.25 (3-1/4") | 0.75 (3/4") | 1-3 Days | $901.99 |
| M90030424S | 900 3-1/8BX3/4K : Magnaloy 900 HUB 3-1/8" BORE X 3/4 KEY SPECIAL | 900 | Keyed | 3.125 (3-1/8") | 0.75 (3/4") | 1-3 Days | $936.99 |
| M90032424S | 900 3-3/4BX3/4K : Magnaloy 900 HUB 3-3/4" BORE X 3/4" KEY SPECIAL | 900 | Keyed | 3.75 (3-3/4") | 0.75 (3/4") | 1-3 Days | $936.99 |
| M90032428 | 900 3-3/4BX7/8K : Magnaloy 900 HUB 3-3/4" BORE X 7/8" KEY | 900 | Keyed | 3.75 (3-3/4") | 0.875 (7/8") | 1-3 Days | $901.99 |
| M90031228 | 900 3-3/8BX7/8K : Magnaloy 900 HUB 3-3/8" BORE X 7/8" KEY | 900 | Keyed | 3.375 (3-3/8") | 0.875 (7/8") | 1-3 Days | $901.99 |
| M90032028 | 900 3-5/8BX7/8K : Magnaloy 900 HUB 3-5/8" BORE X 7/8" KEY | 900 | Keyed | 3.625 (3-5/8") | 0.875 (7/8") | 1-3 Days | $901.99 |
| M90031428S | 900 3-7/16BX7/8K : Magnaloy 900 HUB 3-7/16 BORE X7/8" KEY SPECIAL | 900 | Keyed | 3.4375 (3-7/16") | 0.875 (7/8") | 1-3 Days | $936.99 |
| M90032832 | 900 3-7/8BX1K : Magnaloy 900 HUB 3-7/8" BORE X 1" KEY | 900 | Keyed | 3.875 (3-7/8") | 1" | 1-3 Days | $901.99 |
| M90030032S | 900 3BX1 : Magnaloy 900 HUB 3" BORE X 1 SPECIAL | 900 | Keyed | 3" | 1" | 1-3 Days | $936.99 |
| M90030024 | 900 3BX3/4K : Magnaloy 900 HUB 3" BORE X 3/4" KEY | 900 | Keyed | 3" | 0.75 (3/4") | 1-3 Days | $901.99 |
| M90030020S | 900 3BX5/8K : Magnaloy 900 HUB 3" BORE X 5/8" KEY SPECIAL | 900 | Keyed | 3" | 0.625 (5/8") | 1-3 Days | $970.99 |
| M90041640 | 900 4-1/2BX1-1/4K : Magnaloy 900 HUB 4-1/2" BORE X 1-1/4" KEY | 900 | Keyed | 4.5 (4-1/2") | 1.25 ( 1-1/4") | 1-3 Days | $901.99 |
| M90041632 | 900 4-1/2BX1K : Magnaloy 900 HUB 4-1/2" BORE X 1" KEY | 900 | Keyed | 4.5 (4-1/2") | 1" | 1-3 Days | $901.99 |
| M90040828S | 900 4-1/4B X 7/8K : Magnaloy 900 HUB 4-1/4" BORE X 7/8" KEY SPECIAL | 900 | Keyed | 4.25 (4-1/4") | 0.875 (7/8") | 1-3 Days | $970.99 |
| M90040832 | 900 4-1/4BX1K : Magnaloy 900 HUB 4-1/4" BORE X 1" KEY | 900 | Keyed | 4.25 (4-1/4") | 1" | 1-3 Days | $901.99 |
| M90040432 | 900 4-1/8BX1K : Magnaloy 900 HUB 4-1/8" BORE X 1" KEY | 900 | Keyed | 4.125 (4-1/8") | 1" | 1-3 Days | $901.99 |
| M90042440 | 900 4-3/4BX1-1/4K : Magnaloy 900 HUB 4-3/4" BORE X 1-1/4" KEY | 900 | Keyed | 4.75 (4-3/4") | 1.25 ( 1-1/4") | 1-3 Days | $901.99 |
| M90041232 | 900 4-3/8BX1K : Magnaloy 900 HUB 4-3/8" BORE X 1" KEY | 900 | Keyed | 4.375 (4-3/8") | 1" | 1-3 Days | $901.99 |
| M90042040 | 900 4-5/8BX1-1/4K : Magnaloy 900 HUB 4-5/8" BORE X 1-1/4" KEY | 900 | Keyed | 4.625 (4-5/8") | 1.25 ( 1-1/4") | 1-3 Days | $901.99 |
| M90041432S | 900 4-7/16B X 1K : Magnaloy 900 HUB 4-7/16" BORE X 1" KEY SPECIAL | 900 | Keyed | 4.4375 (4-7/16") | 1" | 1-3 Days | $936.99 |
| M90040032 | 900 4BX1K : Magnaloy 900 HUB 4" BORE X 1" KEY | 900 | Keyed | 4" | 1" | 1-3 Days | $901.99 |
| M900M5014 | 900 50MMBX14MMK : Magnaloy 900 HUB 50MM BORE X 14MM KEY METRIC SPECIAL | 900 | Keyed | 50mm | 14mm | 1-3 Days | $936.99 |
| M900M6016 | 900 60MMBX16MMK : Magnaloy 900 HUB 60MM BORE X 16MM KEY METRIC SPECIAL | 900 | Keyed | 60mm | 18mm | 1-3 Days | $936.99 |
| M900M6018 | 900 60MMBX18MMK : Magnaloy 900 HUB 60MM BORE X 18MM KEY SPECIAL | 900 | Keyed | 60mm | 18mm | 1-3 Days | $936.99 |
| M900M7020 | 900 70MMBX20MMK : Magnaloy 900 HUB 70MM BORE X 20MM KEY SPECIAL | 900 | Keyed | 70mm | 20mm | 1-3 Days | $936.99 |
| M900M74N | 900 74MMBXNOK : Magnaloy 900 HUB 74MM BORE X NO KEY METRIC SPECIAL. | 900 | Keyed | 74mm | NONE | 1-3 Days | $936.99 |
| M900M7520 | 900 75MMBX20MMK : Magnaloy 900 HUB 75MM BORE X 20MM KEY METRIC SPECIAL | 900 | Keyed | 75mm | 20mm | 1-3 Days | $936.99 |
| M900M8022 | 900 80MMBX22MMK : Magnaloy 900 HUB 80MM BORE X22MM KEY METRIC SPECIAL | 900 | Keyed | 80mm | 22mm | 1-3 Days | $936.99 |
| M900R | 900 NO BORE : Magnaloy 900 HUB NO BORE | 900 | Keyed | NONE | NONE | 1-3 Days | $806.99 |
