Description
Magnaloy is the original lightweight, heavy-duty flexible drive coupling. Light weight magnesium construction makes Magnaloy couplings 76 percent lighter than cast iron and 36 percent lighter than aluminum units... and theyÕre stronger than either. The benefits are many... Reduced loads on bearings, shafts and pumps, for longer component life. Easier handling and installation. Rust proof and corrosion resistant. Magnaloys close machining tolerances (TIR of .002Ó) assures vibration-free operation and easy, accurate alignment without need for special tools. Solid magnesium alloy permanent mold castings are heat treated and offer the highest strength-to-weight ratio available. The Premium Line of Magnaloy Couplings comes standard with a single set-screw over the keyway. Optional Double Set-Screws are available at either 45 degree or 90 degree to the keyway. Double set-screws help improve shaft gripping forces by increasing the hoop-stresses generated from tightening a single set-screw. Double set-screws at 45 degrees will produce greater forces than double set-screws at 90 degrees. Either are available upon request by specifying DSS45 or DSS90 following the hub part number, for example M30011210DSS45. Magnaloys Clamp feature is also availble with bored and keyed hubs, specify C following the hub part number, for example M30011210C.
| Product SKU | Model | Coupling Series | Coupling Type | Bore Size | Key Size | Lead Time | Price |
|---|---|---|---|---|---|---|---|
| M10010408C | 100 1-1/8BX1/4K : Magnaloy 100 HUB 1-1/8" BORE X 1/4" KEY W/CLAMP | 100 | Keyed | 1.125 (1-1/8") | 0.25 (1/4") | 1-3 Days | $56.99 |
| M10010408 | 100 1-1/8BX1/4K : Magnaloy 100 HUB 1-1/8" BORE X 1/4" KEY | 100 | Keyed | 1.125 (1-1/8") | 0.25 (1/4") | Same Day | $22.99 |
| M100104N | 100 1-1/8BXNOK : Magnaloy 100 HUB 1-1/8" BORE X NO KEY | 100 | Keyed | 1.125 (1-1/8") | NONE | 1-3 Days | $33.99 |
| M10001604C | 100 1/2BX1/8K : Magnaloy 100 HUB 1/2" BORE X 1/8" KEY W/CLAMP | 100 | Keyed | 0.5 (1/2") | 0.125 (1/8") | 1-3 Days | $56.99 |
| M10001604 | 100 1/2BX1/8K : Magnaloy 100 HUB 1/2" BORE X 1/8" KEY | 100 | Keyed | 0.5 (1/2") | 0.125 (1/8") | Same Day | $22.99 |
| M100016N | 100 1/2BXNOK : Magnaloy 100 HUB 1/2" BORE X NO KEY | 100 | Keyed | 0.5 (1/2") | NONE | 1-3 Days | $33.99 |
| M100M10NC | 100 10MMBW/NOK : Magnaloy 100 HUB 10MM BORE W/NO KEY W/CLAMP | 100 | Keyed | 10mm | NONE | 1-3 Days | $56.99 |
| M100M10N | 100 10MMBW/NOK : Magnaloy 100 HUB 10MM BORE W/NO KEY | 100 | Keyed | 10mm | NONE | 1-3 Days | $33.99 |
| M100M1003 | 100 10MMBX3MMK : Magnaloy 100 HUB 10MM BORE X 3MM KEY | 100 | Keyed | 10mm | 3mm | 1-3 Days | $33.99 |
| M10002206 | 100 11/16BX3/16K : Magnaloy 100 HUB 11/16" BORE X 3/16" KEY | 100 | Keyed | 0.6875 (11/16") | 0.1875 (3/16") | 1-3 Days | $22.99 |
| M100022N | 100 11/16BXNOK : Magnaloy 100 HUB 11/16" BORE X NO KEY | 100 | Keyed | 0.6875 (11/16") | NONE | 1-3 Days | $33.99 |
| M100M1104 | 100 11MMBX4MMK : Magnaloy 100 HUB 11MM BORE X 4MM KEY | 100 | Keyed | 11mm | 4mm | 1-3 Days | $33.99 |
| M100M1204 | 100 12MMBX4MMK : Magnaloy 100 HUB 12MM BORE X 4 MM KEY | 100 | Keyed | 12mm | 4mm | 1-3 Days | $33.99 |
| M100M1205 | 100 12MMBX5MMK : Magnaloy 100 HUB 12MM BORE X 5MM KEY | 100 | Keyed | 12mm | 5mm | 1-3 Days | $33.99 |
| M100M1305 | 100 13MMBX5MMK : Magnaloy 100 HUB 13MM BORE X 5MM KEY | 100 | Keyed | 13mm | 5mm | 1-3 Days | $33.99 |
| M100M14N | 100 14MMBW/NOK : Magnaloy 100 HUB 14MM BORE W/NO KEY | 100 | Keyed | 14mm | NONE | 1-3 Days | $33.99 |
| M100M1403 | 100 14MMBX3MMK : Magnaloy 100 HUB 14MM BORE X 3MM KEY | 100 | Keyed | 14mm | 3mm | 1-3 Days | $43.99 |
| M100M1404 | 100 14MMBX4MMK : Magnaloy 100 HUB 14MM BORE X 4MM KEY | 100 | Keyed | 14mm | 4mm | 1-3 Days | $33.99 |
| M100M1405 | 100 14MMBX5MMK : Magnaloy 100 HUB 14MM BORE X 5MM KEY | 100 | Keyed | 14mm | 5mm | 1-3 Days | $33.99 |
| M100M1503 | 100 15MMBX3MMK : Magnaloy 100 HUB 15MM BORE X 3MM KEY | 100 | Keyed | 15mm | 3mm | 1-3 Days | $33.99 |
| M100M1504 | 100 15MMBX4MMK : Magnaloy 100 HUB 15MM BORE X 4MM KEY | 100 | Keyed | 15mm | 4mm | 1-3 Days | $33.99 |
| M100M1505 | 100 15MMBX5MMK : Magnaloy 100 HUB 15MM BORE X 5MM KEY | 100 | Keyed | 15mm | 5mm | 1-3 Days | $33.99 |
| M100M1604 | 100 16MMBX4MMK : Magnaloy 100 HUB 16MM BORE X 4MM KEY | 100 | Keyed | 16mm | 4mm | 1-3 Days | $33.99 |
| M100M1605C | 100 16MMBX5MMK : Magnaloy 100 HUB 16MM BORE X 5MM KEY CLAMP | 100 | Keyed | 16mm | 5mm | 1-3 Days | $66.99 |
| M100M1605 | 100 16MMBX5MMK : Magnaloy 100 HUB 16MM BORE X 5MM KEY | 100 | Keyed | 16mm | 5mm | 1-3 Days | $33.99 |
| M100M16NC | 100 16MMBXNOK : Magnaloy 100 HUB 16MM BORE X NO KEY CLAMP | 100 | Keyed | 16mm | NONE | 1-3 Days | $66.99 |
| M100M1703 | 100 17MMBX3MMK : Magnaloy 100 HUB 17MM BORE X 3MM KEY | 100 | Keyed | 17mm | 3mm | 1-3 Days | $33.99 |
| M100M1705 | 100 17MMBX5MMK : Magnaloy 100 HUB 17MM BORE X 5MM KEY | 100 | Keyed | 17mm | 5mm | 1-3 Days | $33.99 |
| M100M17N | 100 17MMBXNOK : Magnaloy 100 HUB 17MM BORE X NO KEY | 100 | Keyed | 17mm | NONE | 1-3 Days | $33.99 |
| M100M1806 | 100 18MMBX6MMK : Magnaloy 100 HUB 18MM BORE X 6MM KEY | 100 | Keyed | 18mm | 6mm | 1-3 Days | $33.99 |
| M100M1905 | 100 19MMBX5MMK : Magnaloy 100 HUB 19MM BORE X 5MM KEY | 100 | Keyed | 19mm | 5mm | Same Day | $33.99 |
| M100M1906 | 100 19MMBX6MMK : Magnaloy 100 HUB 19MM BORE X 6MM KEY | 100 | Keyed | 19mm | 6mm | 1-3 Days | $33.99 |
| M10010008C | 100 1BX1/4K : Magnaloy 100 HUB 1" BORE X 1/4" KEY W/CLAMP | 100 | Keyed | 1" | 0.25 (1/4") | 1-3 Days | $56.99 |
| M10010008 | 100 1BX1/4K : Magnaloy 100 HUB 1" BORE X 1/4" KEY | 100 | Keyed | 1" | 0.25 (1/4") | Same Day | $22.07 |
| M10010006 | 100 1BX3/16K : Magnaloy 100 HUB 1" BORE X 3/16" KEY | 100 | Keyed | 1" | 0.1875 (3/16") | 1-3 Days | $22.99 |
| M100100N | 100 1BXNOK : Magnaloy 100 HUB 1" BORE X NO KEY | 100 | Keyed | 1" | NONE | 1-3 Days | $33.99 |
| M100M2004 | 100 20MMBX4MMK : Magnaloy 100 HUB 20MM BORE X 4MM KEY | 100 | Keyed | 20mm | 4mm | 1-3 Days | $33.99 |
| M100M2005 | 100 20MMBX5MMK : Magnaloy 100 HUB 20MM BORE X 5MM KEY | 100 | Keyed | 20mm | 5mm | 1-3 Days | $33.99 |
| M100M2006 | 100 20MMBX6MMK : Magnaloy 100 HUB 20MM BORE X 6MM KEY | 100 | Keyed | 20mm | 6mm | 1-3 Days | $33.99 |
| M100M2008 | 100 20MMBX8MMK : Magnaloy 100 HUB 20MM BORE X 8MM KEY | 100 | Keyed | 20mm | 8mm | 1-3 Days | $33.99 |
| M100M20NC | 100 20MMBXNOK : Magnaloy 100 HUB 20 MM X NO KEY W/CLAMP | 100 | Keyed | 20mm | NONE | 1-3 Days | $66.99 |
| M100M2206 | 100 22MMBX6MMK : Magnaloy 100 HUB 22MM BORE X 6MM KEY | 100 | Keyed | 22mm | 6mm | 1-3 Days | $33.99 |
| M100M2207 | 100 22MMBX7MMK : Magnaloy 100 HUB 22MM BORE X 7MM KEY | 100 | Keyed | 22mm | 7mm | 1-3 Days | $43.99 |
| M100M2208 | 100 22MMBX8MMK : Magnaloy 100 HUB 22MM BORE X 8MM KEY | 100 | Keyed | 22mm | 8mm | 1-3 Days | $43.99 |
| M100M2406 | 100 24MMBX6MMK : Magnaloy 100 HUB 24MM BORE X 6MM KEY | 100 | Keyed | 24mm | 6mm | 1-3 Days | $33.99 |
| M100M2408C | 100 24MMBX8MMK : Magnaloy 100 HUB 24MM BORE X 8MM KEY W/CLAMP | 100 | Keyed | 24mm | 8mm | 1-3 Days | $66.99 |
| M100M2408 | 100 24MMBX8MMK : Magnaloy 100 HUB 24MM BORE X 8MM KEY | 100 | Keyed | 24mm | 8mm | 1-3 Days | $33.99 |
| M100M24NC | 100 24MMBXNOK : Magnaloy 100 HUB 24MM BORE X NO KEY W/CLAMP | 100 | Keyed | 24mm | NONE | 1-3 Days | $64.31 |
| M100M2506 | 100 25 MMBX6 MMK : Magnaloy 100 HUB 25 MM BORE X 6 MM KEY | 100 | Keyed | 25mm | 6mm | 1-3 Days | $33.99 |
| M100M2505 | 100 25MMBX5MMK : Magnaloy 100 HUB 25MM BORE X 5MM KEY | 100 | Keyed | 25mm | 5mm | 1-3 Days | $43.99 |
