FasterSKU: FFH16 1SAE M
1-2 Weeks
Price:
$93.75

Product Details

Data Sheet Click here to download
Usually Ships Within 1-2 Weeks
Factory Location Maumee, Ohio
Port Size 1" ORB
Type Push to Connect
End Connections Connect Under Pressure Not Allowed
Pressure Rating 5076
Series Series: FFH
Operating Force 63 lb
Country of Manufacture Country of Manufacture: Italy
Height 2.32
Length 4.19
Width 2.32
Weight 2.33
Side 1 Gender Male
Side 1 Size 1"

Description

Flat-Face couplings with real maximum working pressure of 35 MPa and Zinc-Nickel plating. Flat valve shut-off system contributes to prevent contamination and spillage. ISO 16028 interchange.
