FasterSKU: 4SRHF08 12SF H
1-2 Weeks
Price:
$55.99

Product Details

Data Sheet Click here to download
Usually Ships Within 1-2 Weeks
Factory Location Maumee, Ohio
Port Size 0.5 (1/2") Female ORB
Type Push to Connect
End Connections Allowed at Working Pressure
Pressure Rating 3625
Series Series: 4SRHF08
Operating Force 57 lb
Country of Manufacture Country of Manufacture: Italy
Height 1.65
Length 4.18
Width 1.65
Weight 1.13
Side 1 Gender Female
Side 1 Size 0.5 (1/2")

Description

Push-pull coupling for high flow rate applications, connectable under residual pressure in both male and female side. Can be screwed directly into valve ports or rigid pipes. Breakaway function. ISO 7241 part A interchange. Flow rate up to 250 l/min.
