4SRHF08 12SF H : Faster Quick Disconnect, Female 1/2" Coupler, 0.5 (1/2") ORB Connection, 3625psi MAWP, 18.49 GPM, ISO 7241 Part A Interchange, Push to Connect Style, Connection Under Pressure Allowed at Working Pressure
4SRHF08 12SF H : Faster Quick Disconnect, Female 1/2" Coupler, 0.5 (1/2") ORB Connection, 3625psi MAWP, 18.49 GPM, ISO 7241 Part A Interchange, Push to Connect Style, Connection Under Pressure Allowed at Working Pressure
4SRHF08 12SF H : Faster Quick Disconnect, Female 1/2" Coupler, 0.5 (1/2") ORB Connection, 3625psi MAWP, 18.49 GPM, ISO 7241 Part A Interchange, Push to Connect Style, Connection Under Pressure Allowed at Working Pressure
4SRHF08 12SF H : Faster Quick Disconnect, Female 1/2" Coupler, 0.5 (1/2") ORB Connection, 3625psi MAWP, 18.49 GPM, ISO 7241 Part A Interchange, Push to Connect Style, Connection Under Pressure Allowed at Working Pressure
4SRHF08 12SF H : Faster Quick Disconnect, Female 1/2" Coupler, 0.5 (1/2") ORB Connection, 3625psi MAWP, 18.49 GPM, ISO 7241 Part A Interchange, Push to Connect Style, Connection Under Pressure Allowed at Working Pressure
4SRHF08 12SF H : Faster Quick Disconnect, Female 1/2" Coupler, 0.5 (1/2") ORB Connection, 3625psi MAWP, 18.49 GPM, ISO 7241 Part A Interchange, Push to Connect Style, Connection Under Pressure Allowed at Working Pressure
Roll over image to zoom in Click on image to zoom
4SRHF08 12SF H : Faster Quick Disconnect, Female 1/2" Coupler, 0.5 (1/2") ORB Connection, 3625psi MAWP, 18.49 GPM, ISO 7241 Part A Interchange, Push to Connect Style, Connection Under Pressure Allowed at Working Pressure4SRHF08 12SF H : Faster Quick Disconnect, Female 1/2" Coupler, 0.5 (1/2") ORB Connection, 3625psi MAWP, 18.49 GPM, ISO 7241 Part A Interchange, Push to Connect Style, Connection Under Pressure Allowed at Working Pressure4SRHF08 12SF H : Faster Quick Disconnect, Female 1/2" Coupler, 0.5 (1/2") ORB Connection, 3625psi MAWP, 18.49 GPM, ISO 7241 Part A Interchange, Push to Connect Style, Connection Under Pressure Allowed at Working Pressure4SRHF08 12SF H : Faster Quick Disconnect, Female 1/2" Coupler, 0.5 (1/2") ORB Connection, 3625psi MAWP, 18.49 GPM, ISO 7241 Part A Interchange, Push to Connect Style, Connection Under Pressure Allowed at Working Pressure4SRHF08 12SF H : Faster Quick Disconnect, Female 1/2" Coupler, 0.5 (1/2") ORB Connection, 3625psi MAWP, 18.49 GPM, ISO 7241 Part A Interchange, Push to Connect Style, Connection Under Pressure Allowed at Working Pressure4SRHF08 12SF H : Faster Quick Disconnect, Female 1/2" Coupler, 0.5 (1/2") ORB Connection, 3625psi MAWP, 18.49 GPM, ISO 7241 Part A Interchange, Push to Connect Style, Connection Under Pressure Allowed at Working Pressure

4SRHF08 12SF H : Faster Quick Disconnect, Female 1/2" Coupler, 0.5 (1/2") ORB Connection, 3625psi MAWP, 18.49 GPM, ISO 7241 Part A Interchange, Push to Connect Style, Connection Under Pressure Allowed at Working Pressure

FasterSKU: 4SRHF08 12SF H
1-2 Weeks
Price:
$59.99

WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects, or other reproductive harm. For more information go to www.P65Warnings.ca.gov.

Product Details

Data Sheet Click here to download
Usually Ships Within 1-2 Weeks
Factory Location Maumee, Ohio
Port Size 0.5 (1/2") Female ORB
Type Push to Connect
End Connections Allowed at Working Pressure
Pressure Rating 3625
Series Series: 4SRHF08
Operating Force 57 lb
Country of Manufacture Country of Manufacture: Italy
Height 1.65
Length 4.18
Width 1.65
Weight 1.13
Side 1 Gender Female
Side 1 Size 0.5 (1/2")

Description

Push-pull coupling for high flow rate applications, connectable under residual pressure in both male and female side. Can be screwed directly into valve ports or rigid pipes. Breakaway function. ISO 7241 part A interchange. Flow rate up to 250 l/min.
