SA-G01-C5-E115-E31 : Nachi Solenoid Valve, 3P4W, D03 (NG6), 26.4GPM, 5075psi, All Ports Blocked Neutral, 115 VAC, DIN with built-in rectifier
SA-G01-C5-E115-E31 : Nachi Solenoid Valve, 3P4W, D03 (NG6), 26.4GPM, 5075psi, All Ports Blocked Neutral, 115 VAC, DIN with built-in rectifier
SA-G01-C5-E115-E31 : Nachi Solenoid Valve, 3P4W, D03 (NG6), 26.4GPM, 5075psi, All Ports Blocked Neutral, 115 VAC, DIN with built-in rectifier
SA-G01-C5-E115-E31 : Nachi Solenoid Valve, 3P4W, D03 (NG6), 26.4GPM, 5075psi, All Ports Blocked Neutral, 115 VAC, DIN with built-in rectifier
SA-G01-C5-E115-E31 : Nachi Solenoid Valve, 3P4W, D03 (NG6), 26.4GPM, 5075psi, All Ports Blocked Neutral, 115 VAC, DIN with built-in rectifier
Roll over image to zoom in Click on image to zoom
SA-G01-C5-E115-E31 : Nachi Solenoid Valve, 3P4W, D03 (NG6), 26.4GPM, 5075psi, All Ports Blocked Neutral, 115 VAC, DIN with built-in rectifierSA-G01-C5-E115-E31 : Nachi Solenoid Valve, 3P4W, D03 (NG6), 26.4GPM, 5075psi, All Ports Blocked Neutral, 115 VAC, DIN with built-in rectifierSA-G01-C5-E115-E31 : Nachi Solenoid Valve, 3P4W, D03 (NG6), 26.4GPM, 5075psi, All Ports Blocked Neutral, 115 VAC, DIN with built-in rectifierSA-G01-C5-E115-E31 : Nachi Solenoid Valve, 3P4W, D03 (NG6), 26.4GPM, 5075psi, All Ports Blocked Neutral, 115 VAC, DIN with built-in rectifierSA-G01-C5-E115-E31 : Nachi Solenoid Valve, 3P4W, D03 (NG6), 26.4GPM, 5075psi, All Ports Blocked Neutral, 115 VAC, DIN with built-in rectifier

SA-G01-C5-E115-E31 : Nachi Solenoid Valve, 3P4W, D03 (NG6), 26.4GPM, 5075psi, All Ports Blocked Neutral, 115 VAC, DIN with built-in rectifier

Save $60.01
NachiSKU: SA-G01-C5-E115-E31
4-6 Weeks
0
Price:
$224.99 $285.00

Product Details

Data Sheet Download Datasheet
Usually Ships Within 4-6 Weeks
Factory Stock 0
Factory Location Greenwood, Indiana
Valve Type Subplate/Manifold Mounted Valve
Valve Interface D03 (NG6)
Flow Rating 26.4
Pressure Rating 5075
Voltage 115 VAC
Actuation Type Solenoid Operated
Solenoid Electrical Connection DIN Connector with Built-In Rectifier
Spool Configuration All Ports Blocked in Neutral
Positions 3-Position
Way 4-Way
Country of Manufacture Japan
Height 8.03
Length 1.81
Width 3.64
Weight 4.41

Description

The Nachi SA-G01 is a standard 3-Position, 4-Way, Solenoid Operated Directional Valve. The movable iron core of the wet type solenoid is immersed in oil, which keeps it lubricated and cushions it from impact and vibration, ensuring very long life. The wet-type solenoid valve also provides very low core switching noise for quiet operation.
