OneHydraulicsSKU: OHI-G-2.5-10K-F
1-3 Days
Price:
$14.99

⚠️ WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects, or other reproductive harm. For more information go to www.P65Warnings.ca.gov.

Product Details

Usually Ships Within 1-3 Days
Material Stainless Steel
Gauge Face Size 2.5"
Gauge Pressure Range 0-10,000psi
Gauge Style Selection Panel Flange
Gauge Connection 1/4" NPT
Country of Manufacture United States
Weight in Lbs 1
Height 3.67 inches
Length 2.72 inches
Width 1.26 inches
Weight 2

Description

The OneHydraulics OHI-G Series Gauges are Glycerine filled, and feature a 304 Stainless Steel Case and Bezel with phosphor Bronze Bourdon Tube, Bronze Connection, and Polycarbonate Lens. This gauge features a built-in snubber, and the display offers both psi and bar readings with a scale up to 10,000psi. Accuracy is +/- 1.6 percent FSD. Temperature Range is -13 deg F to 180 deg F.
