HC4-1.3-A-1 miniBooster Pressure Intensifier, 1.3 Ratio, 3/8" BSPP Inlet Port, 1/2" BSPP Outlet Port, 10.6GPM and 3000psi Inlet, 4.6GPM and 11600psi Outlet, No Dump Valve
HC4-1.3-A-1 miniBooster Pressure Intensifier, 1.3 Ratio, 3/8" BSPP Inlet Port, 1/2" BSPP Outlet Port, 10.6GPM and 3000psi Inlet, 4.6GPM and 11600psi Outlet, No Dump Valve
Roll over image to zoom in Click on image to zoom
HC4-1.3-A-1 miniBooster Pressure Intensifier, 1.3 Ratio, 3/8" BSPP Inlet Port, 1/2" BSPP Outlet Port, 10.6GPM and 3000psi Inlet, 4.6GPM and 11600psi Outlet, No Dump ValveHC4-1.3-A-1 miniBooster Pressure Intensifier, 1.3 Ratio, 3/8" BSPP Inlet Port, 1/2" BSPP Outlet Port, 10.6GPM and 3000psi Inlet, 4.6GPM and 11600psi Outlet, No Dump Valve

HC4-1.3-A-1 miniBooster Pressure Intensifier, 1.3 Ratio, 3/8" BSPP Inlet Port, 1/2" BSPP Outlet Port, 10.6GPM and 3000psi Inlet, 4.6GPM and 11600psi Outlet, No Dump Valve

Save $91.01
miniBoosterSKU: HC4-1.3-A-1
4-6 Weeks
Price:
$1,168.99 $1,260.00

WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects, or other reproductive harm. For more information go to www.P65Warnings.ca.gov.

Product Details

Data Sheet

Download Datasheet

Usually Ships Within 4-6 Weeks
Factory Location Denmark
Valve Style No Dump Valve
Inlet Flow Rate 10.6
Inlet Port 3/8" BSPP
Outlet Port 1/2" BSPP
Outlet Pressure Range 11600
Series HC4
Country of Manufacture Denmark
Height 2.76
Length 5.95
Width 2.76
Weight 8.16

Description

The miniBOOSTER HC4 Hydraulic Intensifier is a compact, high-flow pressure booster designed for hydraulic applications requiring a greater volume of high-pressure oil. This inline hydraulic intensifier accepts inlet pressures from 20 to 207 bar (290 to 3,000 psi) and can generate outlet pressures up to 800 bar (11,600 psi). Eleven available intensification ratios from 1.3:1 to 9.8:1 provide intensified outlet flows up to 17.4 L/min (4.6 GPM), depending on the selected ratio, with maximum inlet flow up to 40 L/min (10.6 GPM). The HC4 automatically stalls when the target pressure is reached and restarts to compensate for oil consumption or leakage. Available configurations include the HC4-A without a dump valve, HC4-B with an integrated dump valve, and HC4-G with proportional pressure control. Typical applications include hydraulic clamping, workholding, presses, machine tools, industrial automation, testing systems, and equipment requiring localized high pressure with higher flow capacity.
