DSV2-100-2NCS-N : Deltrol Solenoid Valve with NO COIL, 2-Way, 2-Position, Normally Closed Spool, C-10-2 Cavity, 3000psi, 6GPM
DSV2-100-2NCS-N : Deltrol Solenoid Valve with NO COIL, 2-Way, 2-Position, Normally Closed Spool, C-10-2 Cavity, 3000psi, 6GPM
DSV2-100-2NCS-N : Deltrol Solenoid Valve with NO COIL, 2-Way, 2-Position, Normally Closed Spool, C-10-2 Cavity, 3000psi, 6GPM
DSV2-100-2NCS-N : Deltrol Solenoid Valve with NO COIL, 2-Way, 2-Position, Normally Closed Spool, C-10-2 Cavity, 3000psi, 6GPM
DSV2-100-2NCS-N : Deltrol Solenoid Valve with NO COIL, 2-Way, 2-Position, Normally Closed Spool, C-10-2 Cavity, 3000psi, 6GPM
Roll over image to zoom in Click on image to zoom
DSV2-100-2NCS-N : Deltrol Solenoid Valve with NO COIL, 2-Way, 2-Position, Normally Closed Spool, C-10-2 Cavity, 3000psi, 6GPMDSV2-100-2NCS-N : Deltrol Solenoid Valve with NO COIL, 2-Way, 2-Position, Normally Closed Spool, C-10-2 Cavity, 3000psi, 6GPMDSV2-100-2NCS-N : Deltrol Solenoid Valve with NO COIL, 2-Way, 2-Position, Normally Closed Spool, C-10-2 Cavity, 3000psi, 6GPMDSV2-100-2NCS-N : Deltrol Solenoid Valve with NO COIL, 2-Way, 2-Position, Normally Closed Spool, C-10-2 Cavity, 3000psi, 6GPMDSV2-100-2NCS-N : Deltrol Solenoid Valve with NO COIL, 2-Way, 2-Position, Normally Closed Spool, C-10-2 Cavity, 3000psi, 6GPM

DSV2-100-2NCS-N : Deltrol Solenoid Valve with NO COIL, 2-Way, 2-Position, Normally Closed Spool, C-10-2 Cavity, 3000psi, 6GPM

Deltrol Fluid ProductsSKU: 10167-81
4-6 Weeks
Price:
$57.99

WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects, or other reproductive harm. For more information go to www.P65Warnings.ca.gov.

Product Details

Data Sheet

Download Datasheet

Usually Ships Within 4-6 Weeks
Factory Location Bellwood, Illinois
Solid Model

Click here to download

Valve Type Solenoid
Style Spool
Flow Rating 6.0
Pressure Rating 3000
Operating Temp Range -30 to +250F
Seal Material NBR
Series DSV
Cartridge Cavity C-10-2
Positions 2-Position
Way 2-Way
Country of Manufacture United States/Vietnam
Height 2
Length 3.81
Width 2
Weight 2

Description

The Deltrol Fluid Products DSV2-100-2NCS Solenoid Directional Two-Way, Two-Position, Normally Closed Spool Cartridge Valve is a versatile hydraulic control component. It can be installed into standard industry cavities or used in pre-configured ported blocks. This valve is designed for bidirectional flow control, blocking flow in both directions when de-energized. When energized, its spool shifts to permit flow in either direction. The valve features a manual override function for easy operation, robust performance with pressures up to 3000 psi and flows up to 6 gpm, and is built with durable materials to ensure long-term reliability.
