DMA-G01-C6-E20 : Nachi Manual Lever Valve, 4-Way, D03 (NG6), 10.5GPM, 5075psi, P Blocked, A&B to T in Neutral, Spring Centered
DMA-G01-C6-E20 : Nachi Manual Lever Valve, 4-Way, D03 (NG6), 10.5GPM, 5075psi, P Blocked, A&B to T in Neutral, Spring Centered
DMA-G01-C6-E20 : Nachi Manual Lever Valve, 4-Way, D03 (NG6), 10.5GPM, 5075psi, P Blocked, A&B to T in Neutral, Spring Centered
DMA-G01-C6-E20 : Nachi Manual Lever Valve, 4-Way, D03 (NG6), 10.5GPM, 5075psi, P Blocked, A&B to T in Neutral, Spring Centered
DMA-G01-C6-E20 : Nachi Manual Lever Valve, 4-Way, D03 (NG6), 10.5GPM, 5075psi, P Blocked, A&B to T in Neutral, Spring Centered
Roll over image to zoom in Click on image to zoom
DMA-G01-C6-E20 : Nachi Manual Lever Valve, 4-Way, D03 (NG6), 10.5GPM, 5075psi, P Blocked, A&B to T in Neutral, Spring CenteredDMA-G01-C6-E20 : Nachi Manual Lever Valve, 4-Way, D03 (NG6), 10.5GPM, 5075psi, P Blocked, A&B to T in Neutral, Spring CenteredDMA-G01-C6-E20 : Nachi Manual Lever Valve, 4-Way, D03 (NG6), 10.5GPM, 5075psi, P Blocked, A&B to T in Neutral, Spring CenteredDMA-G01-C6-E20 : Nachi Manual Lever Valve, 4-Way, D03 (NG6), 10.5GPM, 5075psi, P Blocked, A&B to T in Neutral, Spring CenteredDMA-G01-C6-E20 : Nachi Manual Lever Valve, 4-Way, D03 (NG6), 10.5GPM, 5075psi, P Blocked, A&B to T in Neutral, Spring Centered

DMA-G01-C6-E20 : Nachi Manual Lever Valve, 4-Way, D03 (NG6), 10.5GPM, 5075psi, P Blocked, A&B to T in Neutral, Spring Centered

Save $106.01
NachiSKU: DMA-G01-C6-E20
Same Day
1
100
03.42.F.101A
Price:
$357.99 $464.00

⚠️ WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects, or other reproductive harm. For more information go to www.P65Warnings.ca.gov.

Product Details

Data Sheet Download Datasheet
Usually Ships Within Same Day
Factory Stock 100
Factory Location Greenwood, Indiana
Valve Type Subplate/Manifold Mounted Valve
Valve Interface D03 (NG6)
Flow Rating 10.5
Pressure Rating 5075
Actuation Type Lever Operated
Spool Configuration Motor Spool, P Blocked, A & B to Tank in Neutral
Positions 3-Position
Way 4-Way
Country of Manufacture Japan
Height 5.74
Length 1.81
Width 8.74
Weight 4.41

Description

The Nachi DMA is a standard 3-Position, 4-Way, Lever Operated Directional Valve. Since a balanced type valve is used, there is no need for drain piping. Use with backpressures up to 2320psi is possible.
