Deltrol Fluid ProductsSKU: 10134-43
1-3 Days
Price:
$67.99

⚠️ WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects, or other reproductive harm. For more information go to www.P65Warnings.ca.gov.

Product Details

Data Sheet

Download Datasheet

Usually Ships Within 1-3 Days
Factory Location Bellwood, Illinois
Solid Model

Click here to download

Valve Type Flow Regulator
Adjustment Type Screw Adjustment
Style Spool
Flow Rating 10.0
Pressure Rating 3000
Operating Temp Range -30 to +250F
Seal Material NBR
Series DFRA
Cartridge Cavity C-10-3
Country of Manufacture United States/Vietnam
Height 1
Length 4.74
Width 1
Weight 2

Description

The Deltrol Fluid Products DFRA-100-3 Flow Regulator is an adjustable bypass-type cartridge valve that regulates priority flow while bypassing excess flow, regardless of downstream pressure. It maintains a constant flow rate from 1 to 10 gpm (with a maximum input of 10 gpm) and allows for adjustments of up to 40% of the maximum setting. The valve operates at pressures up to 3000 psi and is designed for reliable performance in temperatures ranging from -30°F to +250°F. It features pressure compensation for accurate flow control, with options for tamper-resistant adjustments and secure locking. Constructed from anodized aluminum, it is ideal for various industrial applications requiring precise flow regulation.
