Product Details
| Data Sheet | Click here to download |
|---|---|
| Usually Ships Within | 3-5 Days |
| Factory Location | Batavia, Illinois |
| Material | Steel |
| Shape | Straight |
| Fitting Style | Rigid |
| Series | B-BTTF |
| Country of Manufacture | Italy |
| Height | 0.25 |
| Length | 2.15 |
| Width | 0.25 |
| Weight | 0.13 |
| Side 1 Size | 1/4 (-04) |
| Side 1 Type | Hose |
| Side 2 Gender | Male |
| Side 2 Size | 7/16-20 (-04) |
| Side 2 Type | Bite Type |
Description
The Alfagomma One-Piece AlfaCrimp B-BTTF Fitting is a straight, carbon steel fitting designed to connect braided hoses to bite-type tube fittings. This fitting uses a non-skive crimp design, meaning there’s no need to remove any part of the hose before installation, which makes the process faster and more efficient. A crimp fitting works by securely compressing the hose onto the fitting, ensuring a strong, leak-proof connection. Braided hoses are flexible hydraulic hoses reinforced with layers of steel wire, offering high strength and resistance to pressure. The bite-type tube fitting securely grips the tube, preventing leaks and ensuring a reliable connection. This AlfaCrimp fitting is ideal for fluid power systems, offering durability and performance in high-pressure applications.
