Product Details
Usually Ships Within | 3-5 Days |
---|---|
Factory Location | Twinsburg, Ohio or Houston, Texas |
Material | Steel |
Side 1 Gender | MALE |
Side 1 Size | M18 X 1.5 (-S10) |
Side 1 Type | HEAVY DUTY DIN TUBE |
Side 2 Gender | MALE |
Side 2 Size | M18 X 1.5 (-S10) |
Side 2 Type | HEAVY DUTY DIN TUBE |
Side 3 Gender | MALE |
Side 3 Size | 9/16-18 (-06) |
Side 3 Type | ORB |
Description
The Series 5179S Branch Tee Male Heavy DIN x Male Heavy DIN x Male Adjustable ORB adapters are robust carbon steel fittings designed to provide secure, leak-free connections in high-pressure hydraulic and fluid power systems. These branch tee adapters feature a three-way design, with two male Heavy DIN (Deutsches Institut für Normung) connections and one male adjustable ORB (O-Ring Boss) connection. The male Heavy DIN connections are ideal for heavy-duty fluid routing, while the male adjustable ORB connection allows for precise adjustments to achieve a reliable, leak-proof seal. Known for their excellent leak prevention, ORB connections make these adapters perfect for demanding applications. Made from carbon steel, the Series 5179S adapters provide superior strength, corrosion resistance, and long-lasting performance, making them suitable for industrial environments that require dependable, flexible, and efficient fluid routing solutions. These adapters ensure secure, reliable fluid connections in even the harshest conditions.
