4M2TX150REEL X150FT : Gates M2T MegaFlex Hose, 100R16, 0.25 (1/4") ID, 0.56" OD, 6000psi Operating, 24000psi Burst, 1.5" Bend, 2-Wire, -40F to +212F, one 150-ft Reel of Hose
Roll over image to zoom in Click on image to zoom
4M2TX150REEL X150FT : Gates M2T MegaFlex Hose, 100R16, 0.25 (1/4") ID, 0.56" OD, 6000psi Operating, 24000psi Burst, 1.5" Bend, 2-Wire, -40F to +212F, one 150-ft Reel of Hose

4M2TX150REEL X150FT : Gates M2T MegaFlex Hose, 100R16, 0.25 (1/4") ID, 0.56" OD, 6000psi Operating, 24000psi Burst, 1.5" Bend, 2-Wire, -40F to +212F, one 150-ft Reel of Hose

GatesSKU: 46574422
Call for Availability
Price:
$833.99

Product Details

Data Sheet Download Datasheet
Usually Ships Within Call for Availability
Factory Location Iola, Kansas
Pressure Rating 6000
Inside Diameter 0.25 (1/4")
Hose Outside Diameter 0.56"
Burst Rating 24000
Bend Radius 1.5
Hose Style 2-Wire Braid
Tube Material Black, oil resistant, synthetic rubber (Nitrile - Type C). See Hose Stock Characteristics for details.
Reinforcement Material Two braids of high-tensile steel wire.
Cover Material Black, oil, abrasion and weather resistant, synthetic rubber (Modified Nitrile - Type C2), with color coded layline. Also available with unique abrasion resistant MegaTuff or XtraTuff cover. See Hose Stock Characteristics for details.
Operating Temp Range -40deg F to +212deg F
Hose Type Standard Hydraulic
Approvals Meets Flame Resistance Acceptance Designation MSHA 2G and ISO11237 2SC R16
Country of Manufacture United States
Weight 34.5

Description

The Gates M2T MegaFlex 2-Wire Braid Hose is recommended for High-pressure hydraulic oil lines. Exceeds SAE 100R16, SAE 100R2, ISO11237 2SC R16 and ISO 1436 2SN R2 requirements and performance requirements of EN 857 2SC and EN 853 2SN. M2T hose has smaller exterior dimensions and significantly tighter bend radius.
