43P-76HP-150SEN : Chase Ultra High Pressure Inline Filter, 20000psi, 3/8" HP, 150 Micron, No Visual Indicator, No Bypass
Roll over image to zoom in Click on image to zoom
43P-76HP-150SEN : Chase Ultra High Pressure Inline Filter, 20000psi, 3/8" HP, 150 Micron, No Visual Indicator, No Bypass

43P-76HP-150SEN : Chase Ultra High Pressure Inline Filter, 20000psi, 3/8" HP, 150 Micron, No Visual Indicator, No Bypass

Chase FiltersSKU: 43P-76HP-150SEN
2-3 Weeks
Price:
$4,080.00

Product Details

Data Sheet Download Datasheet
Usually Ships Within 2-3 Weeks
Factory Location Hampton, Virginia
Material 17-4PH Stainless Steel
Port Size 3/8" HP
Flow Rating 7.5
Micron 150 Micron
Replacement Elements 31E-100SN
O Ring Seals Buna
Valve Options Without Bypass Valve
Pressure Rating 20000
Country of Manufacture United States
Height 4.23
Length 7.1
Width 4.23
Weight 0

Description

The 43-Series 17-4SS In-Line Filters from Chase Filter are rated for operating pressures up to 20,000psi. These filters are made of 17-4PH Stainless Steel Construction and are rated for flows up to 7.5 or 210SCFM.
