31S-16M16M-100SN : Chase High Pressure Inline Filter, 3000psi, #16 SAE (1"), 100 Micron, No Visual Indicator, No Bypass
Roll over image to zoom in Click on image to zoom
31S-16M16M-100SN : Chase High Pressure Inline Filter, 3000psi, #16 SAE (1"), 100 Micron, No Visual Indicator, No Bypass

31S-16M16M-100SN : Chase High Pressure Inline Filter, 3000psi, #16 SAE (1"), 100 Micron, No Visual Indicator, No Bypass

Chase FiltersSKU: 31S-16M16M-100SN
2-3 Weeks
Price:
$2,076.00

Product Details

Data Sheet Download Datasheet
Usually Ships Within 2-3 Weeks
Factory Location Hampton, Virginia
Material 304 Stainless Steel
Port Size #16 SAE (1")
Flow Rating 40
Micron 100 Micron
Replacement Elements 35E-100SN
O Ring Seals Buna
Valve Options Without Bypass Valve
Pressure Rating 3000
Country of Manufacture United States
Height 2.48
Length 2.5
Width 2.48
Weight 0

Description

The 31-Series In-Line Filters from Chase Filter are rated for operating pressures up to 3,000psi. These filters are made of 304 Stainless Steel Construction and are rated for flows up to 40.
