Product Details
Data Sheet | Download Datasheet |
---|---|
Usually Ships Within | 6 Weeks |
Factory Location | Corpus Christi, Texas |
Material | Aluminum Body, Cast Iron Flange and Cover |
Shaft Size | 9T 16/32DP |
Shaft Type | Splined |
Port Location | Rear Ported |
Pressure Rating | 3000 |
Rotation | Clockwise |
Displacement | 22 |
Gpm At 1800 Rpm | 10.46 |
Max Speed | 4000 RPM |
Inlet Port | #12 SAE (3/4") |
Outlet Port | #10 SAE (5/8") |
Mount | SAE A 2-Bolt |
Country of Manufacture | Taiwan |
Height | 4.488 |
Length | 4.477 |
Width | 5.197 |
Weight | 8.71 |
Description
The Honor Gear Pump Group 2 Pumps are defined by the mounting flange and shaft end, as well as the function, be it pump or motor or birotational pump. Mounting flanges are available in SAE A 2-bolt or four-bolt European mounting flanges. Shaft ends can be keyed, spline, or tapered, depending on your requirements. Displacements are available from 0.24 to 2.02 in3. Side ports are generally standard, but rear ports may be available upon request. If you need a pump in a configuration that isn't avaiable online, please give OneHydraulics a call and we'll be happy to help.
