Product Details
| Data Sheet | Download Datasheet |
|---|---|
| Usually Ships Within | Same Day |
| Factory Location | Houston, Texas or Dallas, Texas or Cleveland, Ohio |
| Material | Steel |
| Shape | 90-Degree |
| Pressure Rating | 6000 |
| Series | 2501-FG |
| Country of Manufacture | China |
| Side 1 Gender | MALE |
| Side 1 Size | 7/16-20 (-04) |
| Side 1 Type | JIC |
| Side 2 Gender | MALE |
| Side 2 Size | 1/4-18 (-04) |
| Side 2 Type | NPT |
Description
The Series 2501 90-Degree Angled Male JIC x Male NPT Rigid adapters are high-quality carbon steel fittings designed to create secure, leak-free connections in hydraulic systems. Featuring a 90-degree angle, these adapters are perfect for tight spaces where a strong and reliable connection is required. One end is equipped with a male JIC (Joint Industry Council) 37° flare connection, while the other end has a male NPT (National Pipe Tapered) thread, ensuring a tight seal by deforming the tapered threads. These adapters are ideal for fluid power systems, providing excellent performance and durability in high-pressure applications. The Series 2501 offers a long-lasting, corrosion-resistant solution for industrial systems requiring robust, reliable connections.
