X4H06B30 : OneXtreme Adapter, 0.25 (1/4") Male HP x 0.375 (3/8") Male BSP, 30,000psi
X4H06B30 : OneXtreme Adapter, 0.25 (1/4") Male HP x 0.375 (3/8") Male BSP, 30,000psi
Roll over image to zoom in Click on image to zoom
X4H06B30 : OneXtreme Adapter, 0.25 (1/4") Male HP x 0.375 (3/8") Male BSP, 30,000psiX4H06B30 : OneXtreme Adapter, 0.25 (1/4") Male HP x 0.375 (3/8") Male BSP, 30,000psi

X4H06B30 : OneXtreme Adapter, 0.25 (1/4") Male HP x 0.375 (3/8") Male BSP, 30,000psi

Save $17.61
OneXtremeSKU: X4H06B30
4-6 Weeks
Price:
$58.71 $76.32

⚠️ WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects, or other reproductive harm. For more information go to www.P65Warnings.ca.gov.

Product Details

Data Sheet Download Datasheet
Usually Ships Within 4-6 Weeks
Factory Location Houston, TX
Material 316SS
Pressure Rating 30000
Series OX-HPM-BSPM
Country of Manufacture United States
Height 0.875
Length 1.49
Width 0.875
Weight 0.13
Side 1 Gender MALE
Side 1 Size 0.25 (1/4")
Side 1 Type HP
Side 2 Gender MALE
Side 2 Size 0.375 (3/8")
Side 2 Type BSP

Description

The High Pressure Male to BSP Male OneXtreme Adapters are precision-engineered conversion fittings designed to connect coned-and-threaded high pressure systems to BSPP (British Standard Parallel Pipe) connections in demanding hydraulic, chemical injection, and fluid power applications. The high pressure side utilizes a 60-degree cone and thread connection to create a reliable metal-to-metal seal for applications up to 60,000 psi (4136 bar), while the BSPP side features straight (parallel) threads that seal via a cone, gasket, O-ring, or dowty seal depending on the mating configuration, and may also include an external cone.

Manufactured from cold worked 316 stainless steel, these adapters provide exceptional strength, corrosion resistance, and durability in harsh operating environments, with special materials available upon request to meet specific application requirements. Because this adapter bridges two connection types and pressure classes, the overall system capability must always be based on the lower-rated side and associated components.

Warning: Proper thread identification, sealing method selection, and installation practices are critical—mismatched threads, damaged sealing surfaces, or improper assembly can result in leaks or catastrophic failure; always verify compatibility with mating components and follow recommended installation procedures before use.
