Shop V40/V41 Series Manifold Valves

Follow the steps below to build your V40/V41 Valve Manifold.


Glandless Style

Denoted as 'Gl' Spool in Chart below

  • Exceptional Life as there are no seals to wear

  • Allow for high pressures if externally piloted

  • Higher Internal Leak Rate

  • Flow less than thin lip design

  • More Expensive to Manufacture

Softseal Style

Denoted as 'Ss' Spool in Chart below

  • Lower cycle life as spool & sleeve create air bearing

  • Lower Pressure ranges than Glandless

  • Lower internal Leak Rate

  • Higher Flow Rate for Package Size

  • Less Expensive to Manufacture

Step 1: Select your Valves

2-Position, 5-Way Pilot Actuated Valves

Model

Spool*

Pilot Supply

Pilot Exhaust

Operator

Return

Cv

PSI

Voltage

Connector

Internal

Collected

Solenoid

Spring&Air

0.58

23.2-145

24VDC

Cable Grip

Internal

Collected

Solenoid

Spring&Air

0.58

23.2-145

115VAC

Cable Grip

Internal

Collected

Solenoid

Spring

0.66

29-145

24VDC

Cable Grip

Internal

Collected

Solenoid

Spring

0.66

29-145

115VAC

Cable Grip

2-Position, 5-Way Pilot Actuated Valves

Model

Spool*

Pilot Supply

Pilot Exhaust

Operator

Return

Cv

PSI

Voltage

Connector

Internal

Collected

Solenoid

Solenoid

0.58

29-145

24VDC

Cable Grip

Internal

Collected

Solenoid

Solenoid

0.58

29-145

115VAC

Cable Grip

Internal

Collected

Solenoid

Spring

0.66

29-145

24VDC

Cable Grip

Internal

Collected

Solenoid

Spring

0.66

29-145

115VAC

Cable Grip

3-Position, 5-Way Pilot Actuated Valves, All Ports Blocked

Model

Spool*

Pilot Supply

Pilot Exhaust

Operator

Return

Cv

PSI

Voltage

Connector

Internal

Collected

Solenoid

Solenoid

0.69

29-145

24VDC

Cable Grip

Internal

Collected

Solenoid

Solenoid

0.69

29-145

115VAC

Cable Grip

2-Position, 5-Way Air Pilot Actuated Valves

Model

Spool*

Operator

Return

Cv

Op. PSI

Pilot PSI

Air

Spring

0.58

26"Hg - 232

23.2-232

Air

Spring

0.66

26"Hg - 145

29-145

2-Position, 5-Way Air Pilot Actuated Valves

Model

Spool*

Operator

Return

Cv

Op. PSI

Pilot PSI

Air

Air

0.58

26"Hg - 232

29-232

Air

Air

0.66

26"Hg - 145

29-145

2-Position, 5-Way Air Pilot Actuated Valves

Model

Spool*

Operator

Return

Cv

Op. PSI

Pilot PSI

Air (Priority)

Air

0.58

26"Hg - 232

29-232




Step 2: Select your Bases


Step 3: Select your Accessories
